Condition:
New
Range of Spindle Speed(r.p.m):
23000 - 24000 rpm
Positioning Accuracy (mm):
0.02 mm
No. of Spindles:
Four
Working Table Size(mm):
1300×2500
Machine Type:
CNC Router
Travel (X Axis)(mm):
1300 mm
Travel (Y Axis)(mm):
2500 mm
Repeatability (X/Y/Z) (mm):
0.02 mm
Spindle Motor Power(kW):
6kw
CNC or Not:
CNC
Voltage:
AC 380V/220V or customization
Dimension(L*W*H):
3500*2300*1850
Power (kW):
24
Weight (KG):
2400
Control System Brand:
NC Studio, Syntec
Warranty:
12 Month
Key Selling Points:
High-accuracy
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Bevera
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
2 years
Core Components:
Motor
Bed frame:
Heavy-duty thickening 3.4 meter CNC Router body
Fuselage structure:
Side-hanging gantry structure
Rack:
High precision 1.5 grinding helical rack
Guide:
25MM HIWIN linear guide
Oiling:
Rail automatic oil lubrication system
Spindle speed:
0-18000rpm
Positioning cylinder:
X Axis two,Y Axis three
Limit:
Three-axis induction limit
Push:
Automatic
Knife:
One-button tool setting with automatic tool setting
Local Service Location:
Egypt, Viet Nam, South Africa, Nigeria
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Showroom Location:
Egypt, Viet Nam, South Africa, Nigeria
Marketing Type:
New Product 2020
Certificazione:
CE/ISO
